Multisignal 2.1 Portable Traffic Light set with red time counter
Mobile construction site traffic light WITH red time counter
- Interlock against green/green indicator (cable/radio mode)
- with red time counter
- Pre-programmed standard system (bottleneck, junction) or individual programming
Scope of delivery: 2 signal heads with red time counter and telescopic mast, 2 battery trolleys, 1 control unit, radar sensor and REMA plug (delivered WITHOUT rechargeable battery!)
The Multi-Signal 2.0 comes with a new design, new control unit and red time counter!
We have completely redesigned the Multi-Signal. Externally, the system has been given a slimmer design and new LED optics. The radar sensor is located in the upper half chamber and is therefore protected against vandalism or similar influences. This is installed as standard in all systems.
In addition to the optics, the control system has been redesigned. Among other things, it offers an improved range, the combination of up to 8 signalling devices, 6 different frequencies (automatic frequency selection possible), pre-programmed quick selection buttons for bottlenecks or junctions. Recurring work sites can be memorised in the new user-friendly remote control.
The remote control impresses with its large, illuminated LC display, which clearly shows all the information for the set programming.
The red time counter works in the "quartz function" (automatic and time-controlled calculation of the red phase) and in the aforementioned "traffic-dependent function". After selecting the "quartz function", the following modes are possible: automatic, continuous red, amber flashing, no flashing or manual mode. In emergency mode, the integrated red lamp monitoring system continues to secure the work area by flashing the yellow LEDs. However, the setting of two signal heads to the green phase is locked - this setting is not possible via radio or cable operation. Locking this programming serves to protect drivers and work site personnel from possible accidents.
The red and green phases are calculated automatically by recording the roadworks length and km/h specification. The pre-programmed data query is simple, avoids errors and saves time. Customised adaptations are also possible. The "traffic-dependent control" takes place via the radar sensor. The option of prioritising individual traffic light heads and setting the phase lengths, in combination with the use of the radar sensor, simplifies complicated main and secondary road regulations.
Technical details
It is possible to transmit via 6 frequencies. The frequency is selected automatically, but we recommend selecting a specific frequency to establish a connection more quickly. Data is therefore transmitted in a tested and authorised frequency range. The radio wave reaches a maximum length of 2,500 metres, depending on the surrounding environment.
Currently without TL testing
Are you already using our predecessor model? No problem, the Multisignal 2.0 communicates 100% with its predecessor model, the Multisignal 1.0 and its control terminal.
A suitable solar module can be added. The use of a solar kit significantly extends the operating times and enables self-sufficient summer operation under ideal conditions.
- Interlock against green/green indicator (cable/radio mode)
- with red time counter
- Pre-programmed standard system (bottleneck, junction) or individual programming
- Programme memory for individual programming for fast commissioning of recurring workplaces
- 6 frequencies (Germany), automatic frequency selection, coded
- Automatic light intensity adjustment saves energy and extends battery life
- New version (reduced power consumption = longer runtime)
- Programming depending on time of day and day of week
- Feedback (cable/radio mode)
- Deep discharge protection for accumulators
- Scope of delivery: 2 signal heads with red time counter and telescopic mast, 2 battery trolleys, 1 control unit, radar sensor and REMA plug
